cut off saw+press
l To operate the machine, simply treadle on the foot switch, the machine will automatically perform clamping and cutting for convenient operation.
l Concealed sawblade performs upward cutting. Single or multiple workpieces can be cut simultaneously.
l While cutting, the oil mist splashes automatically for cooling and lubrication.
l Cutting feed is driven by a air/hydraulic combination cylinder for extremely stable cutting speed.
l The machine cabinet painting is baked by high temperature of 200 degree (Powder coating) for resisting bumping without paint peeling off.
l The machine permits 90 and 45 degree cutting.
SUITABLE FOR CUTTING VARIOUS MATERIALS
Aluminum, Brass, heat sink, PVC, plastic steel, Bakelite, acrylic plastic, Teflon, honeycomb board, wood and other non-ferrous metals.
MODEL
COS-24D
Cutting Angle
90 ° or 45 °
Spindle speed
2000R.P.M.
Sawblade size
24"x1"bore
Table area
660x700mm
Table height from floor
830mm
Motor
7 1/2 HP
Air pressure
4-6kg/cm²
Conveyor Length (opt.)
1-7 M
Machine diamesions
( LxWxH )1310x860x1850mm
Packing diamesions
( LxWxH )1430x980x2050mm
N.W. / G.W.
550 / 650kgs
