Wood Lathe
WL-4220
Wood Lathe
l Rotational speed shown by the digital readout.
l Regulate spindle speed with knob.
l With switch for changing forward and reverse.
l Two push button for star and stop.
l Three steps pulley system control by frequency transformer.
l Spindle can be orientated each 15°.
l Interchangeable discs with cutting function.
l With outward tool rest ass’y.
Model
WL-4220
Speed
500~1000rpm, 100~2000rpm, 150~3000rpm
Motor
3HP
Spindle thread
1-1/4"-8TPI
Morse taper
MT2
Max. cutting diameter
510mm
Max. cutting length
1066.8mm
Switch type
Push button & knob switch
Net weight
276 kg
Gross weight
344 kg
CUFT
48.75'
