Disc Sander & Drum Sander
l 370×370mm cast iron table, rib reinforced for maximum stability. The table surface is precision ground.
l Heavy gauge steel frame.
l Rubber drum can be fitted on both ends for full use of the entire spindle.
l The high spindle speed of 1720RPM combined with the oscillating fine finishing effects.
l Easily interchangeable spindle.
l Tilting table for beveled parts sanding.
Model
BOB-TG
Oscillations per minute
29
Oscillation stroke
15/16" (24mm)
Sanding spindle diameter (standard)
1/4", 1/2", 5/8", 1-1/2", 2"
Sanding spindle diameter (optional)
3"
Spindle speed
1720 rpm
Table area
370×370mm
Table tilt
45° front, downward
Table height from floor
465mm
Motor
1/2HP
Dust hood outlet diameter
2"
N.W / G.W.
30.3 / 37.7 kgs
Machine dimensions (L×H×W)
370×370×480mm
Packing dimensions (L×H×W)
435×435×525mm
