Picture Frame Making Machine
FRM-260
Slanting Cutting Machine, Dual Axle, Universal
- Inclined cut
- Striping
- Object removing
Model FRM-260 Main axle Horse power 20 HP Main axle inclinable angle 0°~45°
electric-control for movement of knife axle.Inside vertical axle motor 5 HP
(can install knife head and 6" sawblade)Upper feeding wheel 8 sets (use cylinder power). Lower driving wheel 5 HP, 3 sets , with inverter motor Working object H 7" × W 4" Max. sawblade size 12", center of axle 40mm Packing dimensions L4980×W1400×H1800 mm N.W. 1800 kgs G.W. 2000 kgs
