Profile Sander
PFS-S2W2
4-Side Straight Sanding Machine
Model PFS-S2W2 Min-max working width 15~90 mm Min-max working length 800~3000 mm Min-max working thickness 10~75 mm Sanding belt width 30~90 mm Sanding belt length 2450 mm Belt tilt angle -45°~+90° Belt drive motor and speed 2.2KW×4P / 0~1300RPM (2 sets) Oscillation motor 0.1KW×4P (2 sets) Sanding wheel motor / speed 2.2KW×4P / 0~1800RPM Sanding wheel tilts -10°~+90° Sanding wheel thickness 15~80 mm Sand wheel diameter Ø200 mm Sponge belt width 100 mm Sponge belt length 850 mm Sponge belt size Ø175×100L mm Type of feed Step by step Conveyor drive motor and speed 0.4KW×4P / 0~28 M/min(5 sets) Conveyor width / Quality 100 mm Flat pattern rubber belt Conveyor number 5 Type of material hold down Step by step , roller hold down Type of guide fence Step by step
