Round Bar Making Machine
RBM-100SRH
High Productivity Slicer
Machine Feature
- Specially designed for producing wood slice.
- Saw kerf is only 1.8mm that saving material waste, reducing production cost and creating profits.
- Variable feed speed suits various types of materials with conveneinet speed change.
- Distance between upper and bottom spindle is only 65mm, providing convenient running test and adjustment.
- Specially designed outfeed guide wheel to support the wood slice after cut for smooth outfeed.
- In case overload occurs, all motor stop for safety guard.
Model RBM-100SRH Min. workpiece thickness 3mm Max. workpiece width 100mm Upper spindle 25HP Bottom spindle 25HP Feed motor 1HP Saw blade size (outside dia. x kerf x plate x bore) 1HP Max. working width 100mm(4") spindle speed 4800 R.P.M. Range of feed speed 4-10m/min Dust chute outlet 110mm(4" ) Range of feed speed 3-13m/min Dust chute outlet 100mm(4" ) Machine size ( LxWxH ) 2120x830x1350mm Packing size ( LxWxH ) 2230x985x1520mm Net weight 1100kgs Gross weight 1250kgs
